1.Power supply 2.Input 3. Program/RS232 port 4.HMI/LCD panel 5.keypad 6.Extension/RS485

port 7.Output 8.LAN port

11. PR-E extension module:

1. Power supply&Input terminals 2. Connection cable between CPU and extension(Detached)

3.Extension port(left) 4. RUN/STOP indicator 5. Extension port( Right) 6. Output terminals

Dimensions of PR-E:
