377
120V AC ：Typ. 90 ms
240V AC ：Typ.100 ms
Maximum counting
frequency
Typ. 4Hz
Typ.：4 HZ
Sensor type
Contact or 3-wire PNP
Contact or 3-wire PNP
Isolation between power
supply and inputs
None
Resistive
Isolation between inputs
None
None
Protection against polarity
inversions
Yes
None
Inputs used as analog inputs( I1-I6 )
Measurement range
---
DC 0---10V
Input impedance
---
Min, 24KΩ ; Max. 72KΩ
Input voltage
---
28.8 V DC max
Resolution
---
10bit ,0.01V
Accuracy at 25 °C
---
± (Max.0.02)V
Accuracy at 55 °C
---
± (Max.0.04)V
Isolation between analog
channel and power supply
---
None
Cable length
---
10 m max. shielded and twisted
Output parameters:
Output No.
6 (Q1-Q6)
4 (Q1-Q4) Relay
+2(Q5-Q6)Transistor(PNP)
Output type
Relay output
Continuous current
Resistive load 10A/Inductive load 2A (Relay)
Resistive load
10A/Inductive load 2A
(Relay)
0.3A(Transistor)
Max. breaking voltage
AC 250 V /DC 110 V(Relay)
AC 250 V /DC 110
V(Relay)
DC 30V(Transistor)
Max. Allowable Power Force
1250VA /300W(Relay)
1250VA /300W(Relay)
9W(Transistor)
Electrical durability
Expectancy
10
5
Operations at Rated Resistive Load(Relay)
---
Mechanical life
10
7
Operations at No Load condition(Relay)
---
Response time
Operate Time : 15 mSec. Max.(Relay)
Release Time : 10 mSec. Max.(Relay)
Operate Time : <1 ms
Release Time : <1 ms
Built-in protections
Against short-circuits: None
Against overvoltages and overloads: None
Switch frequency:
Mechanism
10Hz
---
Resistor/light load
2Hz
10HZ
Sensitive load
0.5Hz
0.5HZ
PWM frequency
---
10K HZ(Q5,Q6 must have
