Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-92 DS1000Z Programming Guide
:TRIGger:SLOPe:WHEN
Syntax :TRIGger:SLOPe:WHEN <when>
:TRIGger:SLOPe:WHEN?
Description
Set or query the trigger condition in slope trigger.
Parameter
Name
Type
Range
Default
<when>
Discrete
{PGReater|PLESs|NGReater|NLESs|PGLess|NGLess}
PGReater
Explanation  PGReater/PLESs: you need to specify a time value (refer to :TRIGger:SLOPe:TIME).
The oscilloscope triggers when the positive slope time of the input signal is
greater/lower than the specified time.
 NGReater/NLESs: you need to specify a time value (refer to
:TRIGger:SLOPe:TIME).
The oscilloscope triggers when the negative slope time of the input signal is
greater/lower than the specified time.
 PGLess/NGLess: you need to specify an upper limit (refer
to
:TRIGger:SLOPe:TUPPer) and a lower limit (refer to :TRIGger:SLOPe:TLOWer) of
the time. The oscilloscope triggers when the positive/negative slope time of the input
signal is greater than the specified lower limit and lower than the specified upper
limit.
Return
Format
The query returns PGR, PLES, NGR, NLES, PGL or NGL.
Example
:TRIGger:SLOPe:WHEN NLESs /*Set the trigger condition to NLESs*/
Related
Commands
:TRIGger:SLOPe:TIME
:TRIGger:SLOPe:TUPPer
:TRIGger:SLOPe:TLOWer
:TRIGger:SLOPe:TIME
Syntax :TRIGger:SLOPe:TIME <time>
:TRIGger:SLOPe:TIME?
Description
Set or query the time value in slope trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<time> Real 8ns to 10s
PGReater, NGReater: 1μs
PLESs, NLESs: 2μs
Explanation This command is available when the trigger condition (refer to :TRIGger:SLOPe:WHEN) is
PGReater, PLESs, NGReater and NLESs.
Return
Format
The query returns the time value in scientific notation.
Example
:TRIGger:SLOPe:TIME 0.000003 /*Set the time value to 3μs*/
:TRIGger:SLOPe:TIME? /*The query returns 3.000000e-06*/
Related
Command
:TRIGger:SLOPe:WHEN
