Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-94 DS1000Z Programming Guide
:TRIGger:SLOPe:WINDow
Syntax :TRIGger:SLOPe:WINDow <window>
:TRIGger:SLOPe:WINDow?
Description
Set or query the vertical window type in slope trigger.
Parameter
Name
Type
Range
Default
<window>
Discrete
{TA|TB|TAB}
TA
Explanation  TA: only adjust the upper limit of the trigger level, refer to :TRIGger:SLOPe:ALEVel.
 TB: only adjust the lower limit of the trigger level, refer to :TRIGger:SLOPe:BLEVel.
 TAB: adjust the upper and lower limits of the trigger level at the same time, refer
to :TRIGger:SLOPe:ALEVel and :TRIGger:SLOPe:BLEVel.
Return
Format
The query returns TA, TB or TAB.
Example
:TRIGger:SLOPe:WINDow TB
Related
Commands
:TRIGger:SLOPe:ALEVel
:TRIGger:SLOPe:BLEVel
:TRIGger:SLOPe:ALEVel
Syntax :TRIGger:SLOPe:ALEVel <level>
:TRIGger:SLOPe:ALEVel?
Description Set or query the upper limit of the trigger level in slope trigger. The unit is the same as the
current amplitude unit.
Parameter
Name
Type
Range
Default
<level> Real
(± 5 × VerticalScale from the screen center) -
OFFSet
2V
Explanation For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
Return
Format
The query returns the upper limit of the trigger level in scientific notation.
Example
:TRIGger:SLOPe:ALEVel 0.16 /*Set the upper limit of the trigger level to 160mV*/
:TRIGger:SLOPe:ALEVel /*The query returns 1.600000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet
:TRIGger:SLOPe:BLEVel
