Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-97
:TRIGger:VIDeo:MODE
Syntax :TRIGger:VIDeo:MODE <mode>
:TRIGger:VIDeo:MODE?
Description
Set or query the sync type in video trigger.
Parameter
Name
Type
Range
Default
<mode> Discrete {ODDField|EVENfield|LINE|ALINes} ALINes
Explanation  ODDField: trigger on the rising edge of the first ramp waveform pulse in the odd
field. This type is available when the video standard is NTSC or PAL/SECAM.
 EVENfield: trigger on the rising edge of the first ramp waveform pulse in the even
field. This type is available when the video standard is NTSC or PAL/SECAM.
 LINE: for the NTSC and PAL/SECAM video standards, trigger on the specified line in
the odd or even field; for the 480P and 576P video standards, trigger on the specified
line.
 ALINes: trigger on all the horizontal sync pulses.
Return
Format
The query returns ODDF, EVEN, LINE or ALIN.
Example
:TRIGger:VIDeo:MODE ODDField
Related
Commands
:TRIGger:VIDeo:LINE
:TRIGger:VIDeo:STANdard
:TRIGger:VIDeo:LINE
Syntax :TRIGger:VIDeo:LINE <line>
:TRIGger:VIDeo:LINE?
Description
Set or query the line number when the sync type in video trigger is LINE.
Parameter
Name Type Range Default
<line>
Integer
Refer to Explanation
1
Explanation  NTSC: 1 to 525
 PAL/SECAM: 1 to 625
 480P: 1 to 525
 576P: 1 to 625
Return
Format
The query returns an integer.
Example
:TRIGger:VIDeo:LINE 100
Related
Command
:TRIGger:VIDeo:MODE

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
