Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-122 DS1000Z Programming Guide
:TRIGger:RS232:PARity
Syntax :TRIGger:RS232:PARity <parity>
:TRIGger:RS232:PARity?
Description Set or query the parity type when the trigger condition is ERRor or PARity in RS232
trigger.
Parameter
Name
Type
Range
Default
<parity>
Discrete
{EVEN|ODD|NONE}
NONE
Explanation When the trigger condition is PARity, the parity type cannot be set to NONE. At this
point, the default parity type is ODD.
Return Format
The query returns EVEN, ODD or NONE.
Example
:TRIGger:RS232:PARity EVEN
Related
Command
:TRIGger:RS232:WHEN
:TRIGger:RS232:STOP
Syntax :TRIGger:RS232:STOP <bit>
:TRIGger:RS232:STOP?
Description
Set or query the stop bit when the trigger condition is ERRor in RS232 trigger.
Parameter
Name
Type
Range
Default
<bit> Discrete {1|2} 1
Return Format
The query returns 1 or 2.
Example
:TRIGger:RS232:STOP 2
Related
Command
:TRIGger:RS232:WHEN
:TRIGger:RS232:DATA
Syntax :TRIGger:RS232:DATA <data>
:TRIGger:RS232:DATA?
Description
Set or query the data when the trigger condition is DATA in RS232 trigger.
Parameter
Name
Type
Range
Default
<data>
Integer
0 to 2
n
-1
90
Explanation In 2
n
-1, n is the current data bits and can be 5, 6, 7 or 8.
Return Format
The query returns an integer.
Example
:TRIGger:RS232:DATA 10
Related
Commands
:TRIGger:RS232:WIDTh
:TRIGger:RS232:WHEN

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
