Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-123
:TRIGger:RS232:WIDTh
Syntax :TRIGger:RS232:WIDTh <width>
:TRIGger:RS232:WIDTh?
Description
Set or query the data bits when the trigger condition is DATA in RS232 trigger.
Parameter
Name
Type
Range
Default
<width> Discrete {5|6|7|8} 8
Return Format
The query returns 5, 6, 7 or 8.
Example
:TRIGger:RS232:WIDTh 6
Related
Command
:TRIGger:RS232:WHEN
:TRIGger:RS232:BAUD
Syntax :TRIGger:RS232:BAUD <baud_rate>
:TRIGger:RS232:BAUD?
Description
Set or query the baud rate in RS232 trigger. The default unit is bps.
Parameter
Name
Type
Range
Default
<baud_rate> Discrete
{2400|4800|9600|19200|38400|57600|11
5200|230400|460800|921600|1000000|U
SER}
2400
Return Format
The query returns an integer.
Example
:TRIGger:RS232:BAUD 4800
Related
Command
:TRIGger:RS232:BUSer
:TRIGger:RS232:BUSer
Syntax :TRIGger:RS232:BUSer <user baud>
:TRIGger:RS232:BUSer?
Description
Set or query the user-defined baud rate in RS232 trigger. The default unit is bps.
Parameter
Name
Type
Range
Default
<user baud>
Integer
1 to 900000
9600
Return Format
The query returns an integer.
Example
:TRIGger:RS232:BUSer 50000
Related
Command
:TRIGger:RS232:BAUD

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
