6. OPERATIONS OF THE BASIC FUNCTIONS
IMR02C15-E4
6-36
Screen displays of Function block 21 (F21) to Function block 91 (F91)
Display of F21 to F91 is set to “no display” as factory set value. To display F21 to F91, set mode
selection (no display) screen to “128.”
To display F21 to F91 while any mode transfer screens are hidden, set mode selection (no display)
screen parameter to the sum of the set value of the parameters.
Setting example: Display F21 to F91 while Set data unlock/lock transfer is hidden
Set “130,” the sum of the set value “2” of Set data unlock/lock transfer and “128.”
MODE
0130
SV1
OUT1
OUT
T
DO1 DO
MAN
STOP
DO3
DO4
Mode selection (no display)
“130,” the sum of set value “2” of Set data unlock/lock transfer
and set value “128” that displays F21 and following
Parameters in the Engineering mode (F21 to F70) should be set according to the
application before setting any parameter related to operation. Once the
parameters in the Engineering mode are set correctly, no further changes need
to be made to parameters for the same application under normal conditions. If
they are changed unnecessarily, it may result in malfunction or failure of the
instrument. RKC will not bear any responsibility for malfunction or failure as a
result of improper changes in the Engineering mode.
WARNING
!
To Next Page
