8. PARAMETER DESCRIPTION
IMR02C15-E4
8-95
Dummy
Function block 23 (F23)
This is the first parameter symbol of Function block 23 (F23).
F23
DI assignment
Use to assign the function (SV selection function, interlock release, RUN/STOP
transfer, or Auto/Manual transfer) for the Digital inputs (DI1, DI2).
Data range Factory set value
0 to 7 (Refer to the following table Digital input
(DI) assignment.)
Based on model code
Digital input (DI) assignment
DI1 DI2
Set value
Terminal No.17-18 Terminal No.16-18
0 Unused (No DI assignment)
1 SV selection function (SV1 to SV4)
1
2 SV selection function (SV1 to SV2)
2
RUN/STOP transfer
3
3 SV selection function (SV1 to SV2)
2
Auto/Manual transfer
4
4 SV selection function (SV1 to SV2)
2
Interlock release
5
5 RUN/STOP transfer
3
Auto/Manual transfer
4
6 RUN/STOP transfer
3
Interlock release
5
7 Auto/Manual transfer
4
Interlock release
5
1
SV selection function (SV1 to SV4)
SV1 SV2 SV3 SV4
DI1 Contact open Contact closed Contact open Contact closed
DI2 Contact open Contact open Contact closed Contact closed
2
SV selection function (SV1 to SV2): Contact open state: SV1 Contact closed state: SV2
3
RUN/STOP transfer: Contact open state: STOP Contact closed state: RUN
4
Auto/Manual transfer: Contact open state: Manual Contact closed state: Auto
5
Interlock release: Interlock is released at the time of contact status change (from open to close).
For digital input transfer, refer to following pages.
• SV selection function: Refer to ■ Set the control set value (P. 5-6).
• RUN/STOP transfer: Refer to 6.1 RUN/STOP Transfer (P. 6-6).
• Auto/Manual transfer: Refer to 6.5 Auto/Manual Transfer (P. 6-22).
• Interlock release: Refer to 6.8 Interlock Release (P. 6-41).
F23.
DISL
