8. PARAMETER DESCRIPTION
IMR02C15-E4
8-3
8.1.2 Monitor item
Measured value (PV)/Set value (SV) monitor
Measured value (PV) display (hereafter called PV display):
The Measured value (PV) is displayed.
Set value (SV) display (hereafter called SV display):
The target value for control is displayed. The value to be displayed varies
depending on the state of operation mode.
• Set value (SV)* is displayed when the operation mode is Auto (AUTO)
mode.
*
With the setting change rate limiter when the set value is changed, the displayed set value
changes according to the ramp-up/down rate.
• Manipulated output value (MV) is displayed when the operation mode is
Manual (MAN) mode.
Display or Data range
Factory
set value
Measured value (PV):
Input scale low to Input scale high
Set value (SV):
Setting limiter low to Setting limiter high
Manipulated output value (MV1 or MV2):
PID control:
Output limiter low to Output limiter high
(−5.0 to +105.0 %)
Heat/Cool PID control:
−Cool-side output limiter (high) to
+Heat-side output limiter (high)
(−105.0 to +105.0 %)
In the STOP mode, displays the “SToP” character on the PV or SV
display. Display position of “SToP” can be set in the Engineering mode
(P. 8-97).
When Heat/Cool PID control is performed, it is necessary to select
Output 2 (OUT2) when ordering.
SV display
PV display
28
0
