Current transformer 1 (CT1) input value monitor
Current transformer 2 (CT2) input value monitor
The current value captured by the current transformer (CT) is displayed on the
SV display.
Display range Factory set value
When CT type is CTL-6-P-N:
0.0 to 30.0 A
When CT type is CTL-12-S56-10L-N:
0.0 to 100.0 A
When the current transformer (CT) input is provided, the Current
transformer 1 (CT1) input value monitor is displayed.
Current trasformer 2 (CT2) displays when 2 points are specified for the
current transformer input.
To hide Current transformer 1 (CT1) input value monitor and Current
transformer 2 (CT2) input value, set “No display” to Monitor selection
(P. 8-58) in the Engineering mode.
Related parameters
Engineering mode:
• Monitor selection (no display) (P. 8-58)
Manipulated output value (MV1) monitor [heat-side]
The Manipulated output value (MV1) is displayed on the SV display.
When the control method is Heat/Cool PID action, the Manipulated output
value (MV1) of heat-side is displayed.
Display range Factory set value
Within output limiter range
To hide Manipulated output value (MV1) monitor [heat-side], set “No
display” to Monitor selection (no display) in the Engineering mode
(P. 8-58).
Related parameters
Engineering mode:
• Monitor selection (no display) (P. 8-58)
CT1
CT2
MV
