5. SETUP PROCEDURES PRIOR TO RUNNING THE INSTRUMENT
5-2 IMR02C15-E4
Setup the controller prior to operating the instrument. Refer to the following setup example.
Operation procedure
Setup example:
Input specification: Thermocouple (K) 0 to 400 °C
Control action: PID action with AT (Reverse action)
Event specification (Event 1):
Deviation high/low with hold action (Uses Interlock function)
Control set value: 200 °C
Event set value: 20 °C
PID parameters: Automatic setting by Autotuning (AT)
初期設定
運転設定
Power ON
Check the parameter
related to the in
ut
Check the parameter
related to the control action
Check the parameter
related to the event
Set the control
set value
Set the event set value
運転開始
Change from STOP to
RUN
Tune up PID parameters
[Autotuning (AT) execution]
Operation
Initial Setting
Operation Setting
Operation Start
For operating of initial setting (Engineering mode),
refer to 5.1 Initial Setting (P. 5-3).
For operation setting, refer to 5.2 Operation
Setting (P. 5-6).
For operation start, refer to 5.3 Operation Start
(P. 5-8).
Parameters in the Engineering mode should be set
according to the application before setting any
parameter related to operation. Once the parameters in
the Engineering mode are set correctly, no furthe
changes need to be made to parameters for the same
application under normal conditions. If they are
changed unnecessarily, it may result in malfunction o
failure of the instrument. RKC will not bear any
responsibility for malfunction or failure as a result o
improper changes in the Engineering mode.
WARNING
!
To Next Page
