8. PARAMETER DESCRIPTION
IMR02C15-E4
8-79
Dummy
F07
F07 block selection (no display)
Hide parameter symbols of in the Parameter setting mode from the display.
Data range Factory set value
0: Display
1: No display
0
When “No display” is selected, the parameters of Parameter setting mode
are not displayed; however, F07 parameters are displayed.
For details of setting example, refer to 6.7 Display/No display Setting of
Mode Screens (P. 6-32, P. 6-37).
Related parameter
Parameter setting mode:
• Heater break alarm 1 (HBA1) set value (P. 8-31)
• Heater break alarm 2 (HBA2) set value (P. 8-31)
• Control loop break alarm (LBA) time (P. 8-32)
• LBA deadband (LBD) (P. 8-34)
 Description of function
Hide parameters of the Parameter setting mode from the display. Each parameter of Parameter setting
mode link to the Engineering mode from F01 to F10. The parameters of the Parameter setting mode
linked to the parameters of the Engineering mode is not displayed when “No display” is set to F07
block selection. Those parameters of the Parameter setting mode link to F07 block of the Engineering
mode.
S . F07
Engineering mode
Function block 07 (F07)
Heater break alarm 1 (HBA1) set value
Heater break alarm 2 (HBA2) set value
Control loop break alarm (LBA) time
LBA deadband (LBD)
F07 block selection (no display)
Parameter setting mode
Heater break alarm 1 (HBA1) set value
Heater break alarm 2 (HBA2) set value
Control loop break alarm (LBA) time
LBA deadband (LBD)
Parameter of the F07 block linked
to the Parameter setting mode.
Not displayed when set to
“1: No display” in
F07 block selection (no display).
