8. PARAMETER DESCRIPTION
IMR02C15-E4
8-103
îš„ Description of function
 FAIL
Operation stops if FAIL occurs
(FAIL output [fixed at de-energized]: contact open when error occurs)
FAIL output is ON (contact open) when power is supplied to the instrument only through loader
communication.
 Monitor during RUN
Event ON at RUN (Event OFF at STOP)
Useful for operations such as turning on an indicator lamp or a rotary beacon light.
 Output of the communication monitoring result
Event signal is turned on when communication is not made for 10 seconds.
Settings on Event set value (Parameter setting mode), Event hold action, and Event
differential gap are not available when the Event output is set for FAIL, Monitor during
RUN or output of the Communication monitoring result.
Continued on the next page.
Communication
timing
Communication
timing
10 seconds
When communication is not
performed within 10 seconds
OFF ON OFF
Event status
When normal communication is
performed within 10 seconds
