8. PARAMETER DESCRIPTION
IMR02C15-E4
8-102
Event type
Set
value
Event type Initial setting code
0 None N
1 Deviation high (Using SV monitor value)
1
A (With hold action: E With re-hold action: Q)
2 Deviation low (Using SV monitor value)
1
B (With hold action: F With re-hold action: R)
3 Deviation high/low (Using SV monitor value)
1
C (With hold action: G With re-hold action: T)
4 Band (Using SV monitor value) D
5
Deviation high/low
(SV Using SV monitor value)
[High/Low individual setting]
1
X (With hold action: Y With re-hold action: Z)
6
Band (Using SV monitor value)
[High/Low individual setting]
U
7 SV high (Using SV monitor value) V
8 SV low (Using SV monitor value) W
9 Process high
2
H (With hold action: K)
10 Process low
2
J (With hold action: L)
11 Control loop break alarm (LBA)
3
2
12 Monitor during RUN 4
13 FAIL 3
14
Deviation high (Using local SV)
1

15
Deviation low (Using local SV)
1

16
Deviation high/low
(Using local SV)
1

17
Band (Using local SV)

18
Deviation high/low
(Using local SV)
[High/Low individual setting]
1

19
Band (Using local SV)
[High/Low individual setting]

20
SV high (Using local SV)

21
SV low (Using local SV)

22 Heater break alarm (HBA) 1
23
Output of the communication monitoring
result
5
1
Event hold and re-hold action is available.
2
Event hold action is available.
3
For Heat/Cool control type, the LBA function is not available.
Related parameters
Parameter setting mode
• Event 1 set value (EV1) to Event 4 set value (EV4) (P. 8-20)
• Event 1 set value (EV1) [high] to Event 4 set value (EV4) [high] (P. 8-20)
• Event 1 set value (EV1’) [low] to Event 4 set value (EV4’) [low] (P. 8-22)
Engineering mode:
• Event 1 hold action to Event 4 hold action (P. 8-110)
• Event 1 differential gap to Event 4 differential gap (P. 8-113)
• Event 1 output action at input burnout to Event 4 output action at input
burnout (P. 8-115)
• Energized/De-energized of Event 1 output to Energized/De-energized of
Event 4 output (P. 8-116)
• Event 1 timer to Event 4 timer (P. 8-118)
• Event 1 interlock to Event 4 interlock (P. 8-120)
