8. PARAMETER DESCRIPTION
IMR02C15-E4
8-115
Dummy
F41
Event 1 output action at input burnout
F42
Event 2 output action at input burnout
F43
Event 3 output action at input burnout
F44
Event 4 output action at input burnout
Use to select the output action of the Event 1 at input burnout.
Use to select the output action of the Event 2 at input burnout.
Use to select the output action of the Event 3 at input burnout.
Use to select the output action of the Event 4 at input burnout.
Data range Factory set value
0: Event output is not forcibly turned ON when
the burnout function is activated.
1: ON at over-scale; no action at underscale
2: ON at underscale; no action at over-scale
3: ON at over-scale or underscale
4: OFF at over-scale or underscale
0
Related parameters
Parameter setting mode
• Event 1 set value (EV1) to Event 4 set value (EV4) (P. 8-20)
• Event 1 set value (EV1) [high] to Event 4 set value (EV4) [high] (P. 8-20)
• Event 1 set value (EV1’) [low] to Event 4 set value (EV4’) [low] (P. 8-22)
Engineering mode:
• Event 1 type to Event 4 type (P. 8-101)
• Event 1 hold action to Event 4 hold action (P. 8-110)
• Event 1 differential gap to Event 4 differential gap (P. 8-113)
• Energized/De-energized of Event 1 output to Energized/De-energized of
Event 4 output (P. 8-116)
• Event 1 timer to Event 4 timer (P. 8-118)
• Event 1 interlock to Event 4 interlock (P. 8-120)
Ebo1
Ebo2
Ebo3
Ebo4
