8. PARAMETER DESCRIPTION
IMR02C15-E4
8-118
Dummy
F41
Event 1 timer
F42
Event 2 timer
F43
Event 3 timer
F44
Event 4 timer
Event 1 timer is to set an output delay time for event outputs.
Event 2 timer is to set an output delay time for event outputs.
Event 3 timer is to set an output delay time for event outputs.
Event 4 timer is to set an output delay time for event outputs.
Data range Factory set value
0 to 600 seconds
0
Related parameters
Parameter setting mode
• Event 1 set value (EV1) to Event 4 set value (EV4) (P. 8-20)
• Event 1 set value (EV1) [high] to Event 4 set value (EV4) [high] (P. 8-20)
• Event 1 set value (EV1’) [low] to Event 4 set value (EV4’) [low] (P. 8-22)
Engineering mode:
• Event 1 type to Event 4 type (P. 8-101)
• Event 1 hold action to Event 4 hold action (P. 8-110)
• Event 1 differential gap to Event 1 differential gap (P. 8-113)
• Event 1 output action at input burnout to Event 4 output action at input
burnout (P. 8-115)
• Energized/De-energized of Event 1 output to Energized/De-energized of
Event 4 output (P. 8-116)
• Event 1 interlock to Event 4 interlock (P. 8-118)
EVT1
EVT2
EVT3
EVT4
