Robopac S6 - Coil Technical Specifications; Reel Features; Noise Level

ROBOT S6
3.7. COIL TECHNICAL SPECIFICATIONS
3.7.1.REEL FEATURES
Description Units
of
measur‑
ement
Value
Film spool dimensions (A)
Maximum external diameter (D) mm 300
Reel height (H) mm 500
Film thickness μm 17÷35
Internal diameter (d) mm 50 ¹ - 76
Max weight kg 20
Net spool dimensions (B)
Maximum external diameter (D) mm 300
Reel height (H) mm 500
Internal diameter (d) mm 76
Max weight kg 20
¹ Install the roll-holder shaft provided as an optional.
3.8. NOISE LEVEL
T
he noise levels were measured in com
p
liance with the standards
:
‒ ISO 4871
‒ ISO 11201
Description Measured level of A weighted emission sound
p
ressure, in the operator positio
n
(LpA)
Functioning in working conditions. 66,5 dB (A)
i
Caution - Warning
Prolonged exposure over 80 dB (A) may cause health problems. The use of appropriate protection systems is
recommended (headphones, ear plugs, etc.).
24/94
