ROBOT S6
6. ABOUT THE USE
6.1. RECOMMENDATIONS FOR OPERATION AND USE
‒ Before performing any operation, the operator must make sure that he/she understood the "Instructions
for use".
‒ When using the machine for the first time, the operator must read the manual and identify the controls
and simulate some operations, especially the start-up and shutdown.
‒ Check that all safety devices are installed correctly and in good working order.
‒ Only implement the uses intended by the manufacturer and do not tamper with any device to obtain
performances different from the intended ones.
6.2. CONTROL DESCRIPTION
The illustration shows the main controls
of the machine and the list shows their
description and function.
) Emergency stop push-button: it is used
to stop with a voluntary action, in case of
imminent risk, the organs of the machine
that may pose a rick.
For further details consult the paragraph
"Description of safety devices".
B) User interface: it is used to set or modify
the operating parameters of the
machine.
For further details consult the paragraph
"Description of the user interface".
C) "Start cycle" push-button: it is used to start the automatic wrapping cycle.
D) Light button (white light): It is used to power on/off the controls.
When the light indicator turns on, the relevant function is active.
E) "Reset" push-button: it is used to reset the machine before restarting after an emergency stop or to
restart it after stopping with power supply cut-off.
F) Buttons (retained activation): They are used to manually move the machine.
G) USB port: it allows exchange of data.
6.3. DESCRIPTION OF THE USER INTERFACE
‒ The user interface is equipped with an active matrix colour "touch-screen" display.
