ROBOT S6
4.4.4.LNSTALLATION OF RUDDER
WITH LIGHTENED STEERING
WHEEL (OPTIONAL)
1. Repeat the operations, mentioned in
paragraph “Installation of the feeler and
of the rudder”.
2. Attach the rope (S) to the sheet metal
(T).
|
Important
T
o lower the rudder (V) pull the handle (U).
32/94
