ROBOT S6
5.9.1.STANDARD FEELER
1. Lower the rudder (A).
2. Lift the hood (B).
3. Grip the lever (C).
4. Connect the lever (C) to the tightener
(D).
5. Adjust the tightener (D) following its
path.
6. Disconnect the lever (C) from the
tightener (D).
7. Put back the lever (C).
8. Lower the hood (B).
9. Raise the rudder (A).
5.9.2.LIGHTENED STEERING WHEEL
(OPTIONAL)
1. Open the crank (A).
2. Turn the crank (A) clockwise to increase
the thrust of the feeler (C).
3. Turn the crank (A) anti-clockwise to
decrease the thrust of the feeler (C).
4. Close the crank (A).
The index (B) provides a visual
indication of the thrust of the feeler.
