Chapter 4
SmartGuard™ 600 Controllers Logic Integration
Introduction
In this chapter, you configure your SmartGuard controller and I/O modules by using pre-defined configurations, and
create your safety logic by leveraging pre-configured safety function block logic. In addition, you import faceplate logic
for use with a Logix controller.
Before You Begin
Complete your risk assessment and functional specification. Create a bill of materials based on your application needs.
Load RSNetWorx™ for DeviceNet, RSLogix 5000®, RSLinx® Classic, and FactoryTalk® View Machine Edition software
on your personal computer or workstation.
What You Need
• RSLogix 5000 software
• RSNetWorx for DeviceNet software
•RSLinx software
• Safety Accelerator Toolkit DVD, SAFETY-CL002 or visit the Integrated Architecture® Tools and Resources
website at http://www.ab.com/go/iatools
•Product manuals:
– SmartGuard 600 Controllers User Manual, publication 1752-UM001
– 1769 CompactLogix™ Controllers User Manual (for catalog numbers 1769-L31, 1769-L32C, 1769-
L32CR, 1769-L32E, or 1769-L35E), publication 1769-UM011
– CompactLogix System User Manual (for catalog numbers 1769-L20, 1769-L30), publication 1769-
UM007
– Logix Common Procedures Programming Manual, publication 1756-PM001, if you are not familiar
with programming Logix controllers with RSLogix 5000 software
