Rockwell Automation Publication 750-TG100B-EN-P - June 2019 125

Frame 7 Components Chapter 6

7. Disconnect these cable connectors from the power interface circuit board:

•P3 from J3

•P4 from J4

•P7 from J7

•P8 from J8

•P9 from J9

• P10 from J10

• P11 from J11

J12

J10

J11
