Page #132 background image
132 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 6 Frame 7 Components
2. Without bending the cable to a radius less than 50 mm (2 in.), fully insert
the fiber-optic cable into the transceiver.
3. Insert the transceiver and fiber-optic cable into the port on the board, until
you hear an audible ‘click.’
Current Sense Circuit Board
Replacement
Replace an current sense circuit board with kit catalog number SK-RM-CSB-F7.
Remove the Current Sense Circuit Board
Follow these steps to remove the current sense circuit board from the enclosure.
1. Review the Product Advisories on page 14
.
2. Remove power from the system. See Remove Power from the System on
page 15
.
3. Open the enclosure door.
4. Remove the protective guard. See Remove the Protective Guard on page
110
.
5. Remove the LCL filter module from the enclosure. See Remove the LCL
Filter Module from the Enclosure on page 127
.
