Rockwell Automation Publication 750-TG100B-EN-P - June 2019 283
Chapter 10
Wire Entry/Exit Bay Components
This chapter provides detailed instructions for how to remove and replace wire
entry/exit bay components.
Wire Entry/Exit Bay Kits
Tab le 23 lists the replacement kits available for wire entry/exit bay
(frames 8…15).
Table 23 - Wire Entry/Exit Bay Replacement Kits
Description Catalog Number Identification Identification No. Replacement Instructions
Ventilation Components
IP21/IP54, 400 mm Wide Door Vent Filter SK-RM-WBDR-FLTR1 See Figure 23 on page 284 1See page 285
IP21/IP54, 800 mm Wide Door Vent Filter SK-RM-WBDR-FLTR1 1 See page 285
IP21/IP54, 400 mm Wide Door Vent Fan
and Filter
SK-RM-WBDR-FANFLR1 2 See page 285
IP21/IP54, 800 mm Wide Door Vent Fan
and Filter
SK-RM-WBDR-FANFLR2 2 See page 285
Electrical Components
Thermal Switch SK-RM-THRMSW-WB See Figure 23 on page 284 3See page 287
