Rockwell Automation Publication 750-TG100B-EN-P - June 2019 143

Control Bay and Control Pod Components Chapter 7

Install the IP21/IP54 Roof Vent Filter

Install the IP21/IP54 roof vent filter in the reverse order of removal.

IP54/IP21 Roof Vent Fan

Replacement

Replace an IP21/IP54 roof vent fan on a control or input bay with kit catalog

number SK-RM-IBFAN1-F8.

Remove the IP21/IP54 Roof Vent Fan

Follow these steps to remove the IP21/IP54 roof vent fan.

1. Review the Product Advisories on page 14

2. Remove power from the system. See Remove Power from the System on

page 15

3. Open the control bay or input bay enclosure door.

IMPORTANT Verify that the ‘X’ on the filter media is on the side that faces away from the

roof vent.
