124 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 6 Frame 7 Components
2. Without bending the cable to a radius less than 50 mm (2 in.), fully insert
the fiber-optic cable into the transceiver.
3. Insert the transceiver and fiber-optic cable into the port on the board, until
you hear an audible ‘click.’
Power Interface Circuit
Board Replacement
Replace a power interface circuit board with the kit catalog number for your
power module rating:
Remove the Power Interface Circuit Board
Follow these steps to remove the power interface circuit board.
1. Review the Product Advisories on page 14
.
2. Remove power from the system. See Remove Power from the System on
page 15
.
3. Open the enclosure door.
4. Remove the protective guard. See Remove the Protective Guard on page
110
.
5. Remove the power module from the enclosure. See Remove the Power
Module from the Enclosure on page 113
.
6. Remove the power layer interface circuit board from the power module.
See Power Layer Interface Circuit Board Replacement on page 120
.
Power Module Rating Power Interface Circuit Board Kit Cat. No.
400V 302A, 480V 302A SK-RM-PIB4-C302D302
400V 367A, 480V 361A SK-RM-PIB4-C367D361
400V 460A, 480V 430A SK-RM-PIB4-C460D430
400V 540A, 480V 505A SK-RM-PIB4-C540D505
400V 585A, 480V 540A SK-RM-PIB4-C585D540
