84 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 5 Frame 6 Components

Install the DR and PE-A (EMC & MOV) Jumper

Install the DR and PE-A (EMC & MOV) jumper in the reverse order of removal.

• Verify that the jumper is installed in the correct position as required for

your grounding scheme and application. See the PowerFlex 750-Series

Products with TotalFORCE Control, Installation Instructions,

publication 750-IN100

, for jumper configuration.

Fan Power Supply Circuit

Board Replacement

Replace a fan power supply circuit board with kit catalog number

SK-RM-PSB1-F5-F6.

Remove the Fan Power Supply Circuit Board

Follow these steps to remove the fan power supply circuit board.

1. Review the Product Advisories on page 14

2. Remove power from the system. See Remove Power from the System on

page 15

3. Remove the cover from the chassis. See Remove the Cover on page 76
