86 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 5 Frame 6 Components

5. Remove the six M4 x 10 mm slotted-torx screws that secure the fan power

supply circuit board to the mounting plate and remove the circuit board.

Install the Fan Power Supply Circuit Board

Install the fan power supply circuit board in the reverse order of removal.

M4 x 10 mm

T20 or F - 6.4 mm (0.25 in.)

2.3 N

•m (20 lb•in)
