176 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 8 Input Bay Components

Figure 12 - Input Bay Frame 8 and 9 AC Precharge Module Kits Identification

Frame 8 AC Precharge Module

Frame 9AC Precharge Module
