Rockwell Automation Publication 750-TG100B-EN-P - June 2019 203
Power Bay Components Chapter 9
Heatsink Fan Fuse SK-RM-INVFAN1-FUSE See Figure 21 on page 209 20 See page 275
Heatsink Fan Assembly SK-RM-INVFAN1-F8 21 See page 276
Accessories Kits
Torque Accuracy Module 20-750-MTAM1-CD (400/480V)
20-750-MTAM1-EF (600/690V)
See Figure 22 on page 210 24 See page 277
DC Bus Conditioner 20-750-MDCBUS-COND 25 See page 279
(1) “MI1” identifies a power module with no paralleling inductor and no reflected wave filter. “MI2” identifies a power module with a paralleling inductor only. “MI3” identifies a power module with a
reflected wave filter only. “C” and “D” in “CnnnDnnn” identifies a power module that is rated for 400/480V, respectively. “E” and “F” in “EnnnFnnn” identifies a power module that is rated for 600/
690V, respectively. “nnn” in “CnnnDnnn” and “EnnnFnnn” identifies the power module amp rating.
(2) “PIB1” identifies a circuit board compatible with a power module with no paralleling inductor and no reflected wave filter. “PIB2” identifies a circuit board compatible with a power module with a
paralleling inductor only. “PIB3” identifies a circuit board compatible with a power module with a reflected wave filter only. “C” and “D” in “CnnnDnnn” identifies a circuit board compatible with a
power module that is rated for 400/480V, respectively. “E” and “F” in “EnnnFnnn” identifies a circuit board compatible with a power module that is rated for 600/690V, respectively. “nnn” in
“CnnnDnnn” and “EnnnFnnn” identifies the amp rating the power module that the circuit board is compatible with.
(3) “C” and “D” in “CnnnDnnn” identifies an LCL filter module that is rated for 400/480V, respectively. “E” and “F” in “EnnnFnnn” identifies an LCL filter module that is rated for 600/690V, respectively.
“nnn” in “CnnnDnnn” and “EnnnFnnn” identifies the LCL filter module amp rating.
Table 19 - Power Bay Replacement Kits (Continued)
Description Catalog Number Identification Identification No. Replacement Instructions
