Rockwell Automation Publication 750-TG100B-EN-P - June 2019 253

Power Bay Components Chapter 9

5. Remove the three M6 x 16 mm torx screws that secure the right-side cover

to the power module chassis and remove the cover.

M6 x 16 mm

T30

5.2 N•m (46 lb•in)
