46 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 3 Component Inspection and Test Procedures
IP54 door filters:
• Control bay - see page 145
.
• Input bay, 400/600 mm wide - see page 179
.
• Input bay, 800/1000 mm wide - see page 182
.
• Power bay, 400/600 mm wide - see page 220
.
• Power bay, 800 mm wide - see page 222
.
• Wire entry/exit bay, 400 mm wide - see page 285
.
• Wire entry/exit bay, 800 mm wide - see page 285
.
4. Remove the filters from the exhaust vent assemblies and inspect for dirt
buildup or blockage. Clean or replace all filters as necessary. See these
procedures for removal instructions:
IP54 exhaust vent filters:
• Control bay - see page 142
.
• Input bay - see page 179
.
• Power bay - see page 211
.
5. Inspect the enclosure fan assemblies for blockage and verify free rotation.
Clean or replace as necessary. See these procedures for removal
instructions:
• Frame 5 mixing fan (see page 61
) and heatsink fan (page 62).
• Frame 6 mixing fan (see page 81
) and heatsink fan (see page 82).
• Control bay roof vent fan - see page 143
.
• Input bay roof or door vent fans - see page 179
or 182.
• Power bay IP54 roof vent fans - see page 214
.
• Frame 7 power and LCL filter module fan assembly - see page 109
.
• Frames 8…15 LCL filter module fan assembly - see page 276
.
• Frames 8…15 power module fan assembly - see page 276
.
• Entry/Exit wire bay door vent fan - see 285
.
6. Remove the cover from the control pod and inspect all visible major
components, including: circuit boards, wire harnesses, fiber-optic cables,
and connectors. If any components show evidence of burn marks or
breakage, replace the damaged components without further testing.
• For frame 5, see step 3 only in Remove the Main Control Circuit Board
on page 57
.
• For frame 6, see step 3 only in Main Control Circuit Board
Replacement on page 77
.
• For frame 7, see Remove the Control Pod Cover on page 98
.
• For frames 8…15, see Control Pod Cover Removal on page 146
.
7. For frames 5 and 6, inspect the power feedback circuit board. If any
components, particularly the resistors, show evidence of burn marks or
breakage, replace the circuit board without further testing. For frame 5, see
page 67
. For frame 6, see page 87.
