Roland INTEGRA-7

Studio Set – MASTER EQ tab
14
Parameter Value Explanation
MASTER EQ tab
Master EQ Switch OFF, ON Master EQ on/o setting
EQ Low Freq 200, 400 [Hz] Frequency of the low range
EQ Low Gain -15–+15 [dB] Gain of the low frequency range
EQ Mid Freq
200, 250, 315, 400, 500, 630, 800,
1000, 1250, 1600, 2000, 2500, 3150,
4000, 5000, 6300,8000 [Hz]
Frequency of the middle range
EQ Mid Gain -15–+15 [dB] Gain of the middle frequency range
EQ Mid Q 0.5, 1.0, 2.0, 4.0, 8.0
Width of the middle frequency range
Set a higher value for Q to narrow the range to be aected.
EQ High Freq 2000, 4000, 8000 [Hz] Frequency of the high range
EQ High Gain -15–+15 [dB] Gain of the high frequency range
