92
MFX Parameters
Specications of each Speaker Type
The speaker column indicates the diameter of each speaker unit (in
inches) and the number of units.
Type Cabinet Speaker Microphone
SMALL 1 small open-back enclosure 10 dynamic
SMALL 2 small open-back enclosure 10 dynamic
MIDDLE open back enclosure 12 x 1 dynamic
JC-120 open back enclosure 12 x 2 dynamic
BUILT-IN 1 open back enclosure 12 x 2 dynamic
BUILT-IN 2 open back enclosure 12 x 2 condenser
BUILT-IN 3 open back enclosure 12 x 2 condenser
BUILT-IN 4 open back enclosure 12 x 2 condenser
BUILT-IN 5 open back enclosure 12 x 2 condenser
BG STACK 1 sealed enclosure 12 x 2 condenser
BG STACK 2 large sealed enclosure 12 x 2 condenser
MS STACK 1 large sealed enclosure 12 x 4 condenser
MS STACK 2 large sealed enclosure 12 x 4 condenser
METAL STACK large double stack 12 x 4 condenser
2-STACK large double stack 12 x 4 condenser
3-STACK large triple stack 12 x 4 condenser
56: GuitarAmpSim -> Delay
Balance W
L in
R in
L out
R out
Pre Amp
Speaker
Feedback
Delay
Balance W
Balance D
Parameter Value Explanation
Amp Sw OFF, ON Turns the amp switch on/o.
Amp Type
Type of guitar
amp
JC-120, CLEAN TWIN, MATCH DRIVE,
BG LEAD, MS1959I, MS1959II,
MS1959I+II, SLDN LEAD, METAL5150,
METAL LEAD, OD-1, OD-2, TURBO,
DISTORTION, FUZZ
Amp Volume # 0–127
Volume and amount of distortion
of the amp
Amp Master # 0–127 Volume of the entire pre-amp
Amp Gain
LOW, MIDDLE,
HIGH
Amount of pre-amp distortion
Amp Bass
0–127
Tone of the bass/mid/treble
frequency range
* Middle cannot be set if “Match
Drive” is selected as the Pre Amp
Type.
Amp Middle
Amp Treble
Delay Switch # OFF, ON Delay on/o
Delay Time # 0–1300 ms
Adjusts the delay time from the
direct sound until the delay sound
is heard.
Delay Feedback
#
-98–+98 %
Adjusts the proportion of the delay
sound that is fed back into the
eect. Negative “-” settings will
invert the phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Frequency at which the high-
frequency portion of the delay
sound will be cut (BYPASS: no cut)
Delay Balance #
D100:0W–
D0:100W
Adjusts the volume balance
between the sound that is sent
through the delay (W) and the
sound that is not sent through the
delay (D).
Parameter Value Explanation
Speaker Sw OFF, ON
Selects whether the sound will be
sent through the speaker simulation
(ON) or not (OFF)
Speaker Type
(See the table
below.)
Type of speaker
Level 0–127 Output Level
Specications of each Speaker Type
The speaker column indicates the diameter of each speaker unit (in
inches) and the number of units.
Type Cabinet Speaker Microphone
SMALL 1 small open-back enclosure 10 dynamic
SMALL 2 small open-back enclosure 10 dynamic
MIDDLE open back enclosure 12 x 1 dynamic
JC-120 open back enclosure 12 x 2 dynamic
BUILT-IN 1 open back enclosure 12 x 2 dynamic
BUILT-IN 2 open back enclosure 12 x 2 condenser
BUILT-IN 3 open back enclosure 12 x 2 condenser
BUILT-IN 4 open back enclosure 12 x 2 condenser
BUILT-IN 5 open back enclosure 12 x 2 condenser
BG STACK 1 sealed enclosure 12 x 2 condenser
BG STACK 2 large sealed enclosure 12 x 2 condenser
MS STACK 1 large sealed enclosure 12 x 4 condenser
MS STACK 2 large sealed enclosure 12 x 4 condenser
METAL STACK large double stack 12 x 4 condenser
2-STACK large double stack 12 x 4 condenser
3-STACK large triple stack 12 x 4 condenser
To Next Page
