142
Chapter 8 Appendix
8-1 Usable Media
Conditions for Usable Media
Media width
10-1/4 to 54 inches (260 to 1,371 mm)
A) Cuttable media thickness
0.08 to 0.22 mm (3.2 to 8.6 mil)
(depending on media composition)
B) Maximum media thickness (including backing paper)
Printing only: 1.0 mm (39 mil)
When performing cutting: 0.4 mm (15 mil)
C) Roll outer diameter
180 mm
D) Paper tube (core) inner diameter
50.8 mm or 76.2 mm (2 inches or 3 inches)
Roll weight
30 kg (66 lb.)
Other conditions
Media such as the following cannot be used.
➢ Media whose end is attached to the paper tube (core)
➢ Media which is severely warped or which has a strong tendency to reroll
➢ Media that cannot withstand the heat of the media heating system
➢ Media that cannot withstand the tensioning of the media take-up or feed system
➢ Media whose paper tube (core) is bent or crushed
➢ Media that bends under its own weight when loaded
This machine cannot necessarily print every kind of media. When selecting media, be sure to carry out testing in
advance to make sure that satisfactory printing quality is obtained.
C
D
AB
