Maintenance
Edition BE210202
03.2022
Rondostar 5000
Operating manual
129
7.4.9 Automatic flour duster: Adjusting the brush
[variant SSH670**.*][standard SSH672***.*, SSH673***.*]
1. Loosen the brush (1) by means of the two screws (2) (front and
rear) on the container (3).
2. Adjust the brush (1)
3. Tighten screws (2) again.
7.4.10 Cutomat: Replacing the guideway [SSH67***C.*]
Due to the risk of injury at the sharp edges, cutting rollers must be re-
placed carefully and correctly. Wear suitable protective gloves to pre-
vent injuries. Cutting rollers that are outside the cutting point must be
placed in the holding brackets beneath the machine table.
1. Open the safety guard (1).
2. Remove the cutting roller (2).
3. Replace the guideway (3).
4. Insert the cutting roller (2).
5. Close the safety guard (1).
3
1
2
37
1 2
3
