Rondo Rondostar 5000 Basic - Mounting the Dough Catch Pans; Folding up the Machine Table [SSH670*.*; SSH672*.*; SSH672*C.*]; Folding up the Machine Table: Cutomat [SSH672**C.*; SSH673**C.* ]

Transporting, setting up, connecting, dismounting and storing the device
Edition BE210202
03.2022
Rondostar 5000
Operating manual
43
2.5.7 Mounting the dough catch pans
1. Remove protective film from the dough catch pan (1).
2. Insert the dough catch pan on both sides.
3. Raise the machine table (3).
2.5.8 Folding up the machine table [SSH670*.*/ SSH672*.* / SSH672*C.*]
When raising the machine table, push in or remove the dough catch
pan.
1. Attach the table hook (2).
The machine table (1) is now secured.
2.5.9 Folding up the machine table: Cutomat [SSH672**C.* / SSH673**C.* ]
A defective locking lever (1) must be replaced immediately!
Reason: Risk of injury from falling machine table!
1. Remove the cutting rollers.
2. Fold up the machine table until the locking lever (1) locks.
1
2
2
1
10
1
