General information on the machine
Edition BE210202
03.2022
Rondostar 5000
Operating manual
71
3.6.1.4 Touch screen
The touch screen (1) lets you select functions and display data on the
user interface of the software (visualisation).
3.6.1.5 Automatic flour duster: Dosing slides
[variant SSH670**.*][standard SSH672**.*, SSH673**.*]
The desired dosing width can be set with the dosing slides (1). The
maximum dusting width is 630 mm.
The dusting flour consumption can be considerably reduced by setting
the dosing slides (1) to the actually required dusting width.
3.6.1.6 Cutomat: Tension lever / stop lever [SSH67***C.*]
The height of the cutting roller (1) is set with the tension lever (2). The
stop lever (3) locks the tension lever (2).
1
1
1
2
3
