Operation
Edition BE210202
03.2022
Rondostar 5000
Operating manual
93
Working position of the automatic reeling device (closed)
Before the last pass of the dough through the roller in a program with
activated reeler, the reeling device (5) closes automatically. The device
folds down, and the dough reeler is held with the lower and upper roll-
ers (7).
The dough band is reeled up, and the upper rollers (7) swing up.
At the end of the sheeting process, the device swivels back into its
basic position.
The reeled dough band (6) remains on the machine table.
5.10 Cutomat with cutting station [SSH67***C.*]
Safety guards
The cutting equipment is covered by a safety guard (1).
A defective gas spring (5) on the safety guard (1) must be replaced
immediately! Reason: Risk of injury from falling safety guard!
5
6
7
1
5
10
