General information on the machine
Edition BE210202
03.2022
Rondostar 5000
Operating manual
72
3.6.2 Safety elements
3.6.2.1 Safety guards
Safety guards (1) protect the operator from accidental contact with
dangerous parts of the installation and moving elements.
The machine stops immediately when a safety guard (1) is opened.
Raising the safety guards (1) even slightly must stop the machine.
When the safety guards (1) are closed, the machine must not restart
automatically.
After the machine has been stopped by opening a safety guard (1), the
machine must be restarted.
3.6.2.2 Gas spring
The gas spring (1) protects the operator against the safety guard drop-
ping.
[SSH673***.*]
The gas spring (2) protects the operator against the machine table
dropping.
1 1
1
2
