Rondo Rondostar 5000 Basic - Lowering the Cutting Rollers; Lifting the Cutting Rollers

Operation
Edition BE210202
03.2022
Rondostar 5000
Operating manual
96
5.10.3 Lowering the cutting rollers
Close the safety guard (1)
1. Lift the tension lever (3) slightly and turn the stop lever (4) anti-
clockwise to the limit stop.
2. Lower the tension lever (3) gradually until the cutting roller (2)
rests on the conveyor belt.
The further down the tension lever (3) is lowered, the greater the cut-
ting pressure.
When using a length cutting roller, make sure to watch out for the
following:
As soon as the length cutting rollers touch down on the conveyor
belt, lower the tension lever by no more than 2 steps, otherwise
the belt may be cut.
5.10.4 Lifting the cutting rollers
1. Gently push down the tension lever (1).
2. Turn the stop lever (2) clockwise to the limit stop.
3. Release the tension lever (1) and lift it to the limit stop.
36
1
2
3
4
1
2
