Operation
Edition BE210202
03.2022
Rondostar 5000
Operating manual
92
5.9 Automatic reeling device [SSH67*7H*.*]
Function of the automatic reeling device
The automatic reeling device is started automatically by the electrical
control. Handle with care! Do not reach into the stationary or running
device!
Basic position of the automatic reeling device (open).
Dough retention bail (1)
If, when sheeting large dough blocks, the dough band does not run
through the opening between the machine table and the reeling de-
vice, but pushes against the dough retention arm (1), this can be re-
moved.
• Loosen and remove the plastic screw (2).
Side plate (4)
• Insert the dough reeler (3) correctly into the side plates (4).
20
1
2
3
4
Side plates
