Rondo Rondostar 5000 Basic

To Next Page

To Previous Page

General information on the machine

Edition BE210202

03.2022

Rondostar 5000

Operating manual

3.3.4 Type plate

A Year of manufacture

B Manufacturer

C Product name

D Model number

E Machine number

A B C

D E
