Transporting, setting up, connecting, dismounting and storing the device
Edition BE210202
03.2022
Rondostar 5000
Operating manual
37
2.5.2 Mounting the machine tables
1. Remove all protective films on stainless machine parts.
2. Lift the machine table (4) with a second person.
3. Guide the centre of the drive roller of the machine table onto the
spring bolt (1) in the rear housing (2).
4. Move the machine table back, applying strong pressure.
5. Centre the driver (3) of the drive roller of the machine table in the
holding device (5) of the front housing.
To engage the machine table, proceed as follows:
6. Lightly pull the conveyor belt (6) until the driver engages.
1
2
4
3
5
6
