Transporting, setting up, connecting, dismounting and storing the device
Edition BE210202
03.2022
Rondostar 5000
Operating manual
31
1. Lift the machine using the guard tube (1) until the front wheel
engages.
2. Roll the machine so the rear side is at the edge of the pallet.
3. From the rear side of the machine, move the manual pallet jack
towards the pallet.
4. Raise the fork of the manual pallet jack to the height of the pallet.
5. Secure the manual pallet jack to prevent it from rolling away.
6. Two of you should hold the machine by the guard tube (1).
7. The third person ensures that the manual pallet jack is secure.
8. Push the machine onto the manual pallet jack until the rear
wheels (2) have reached the edge of the pallet but are still on the
pallet, as shown in the illustration.
(Pay attention to the centre of gravity, can tip! Take care not to
trip!)
9. Raise the fork (3) of the manual pallet jack.
10. Pull the manual pallet jack and the deposited machine backwards.
11. At the same time, two of you should hold the machine by the
guard tube (1) and push it off the pallet.
(Pay attention to the centre of gravity, can tip! Take care not to
trip!)
1
1
2 3
