Transporting, setting up, connecting, dismounting and storing the device
Edition BE210202
03.2022
Rondostar 5000
Operating manual
33
if fork height > 7.5 cm:
16. Raise the fork (3) of the manual pallet jack.
17. Place wooden braces (4) under the substructure.
X = 30 cm, for secure handling
18. Lower the fork (3) of the manual pallet jack.
19. Pull the manual pallet jack out somewhat.
20. Lift the machine with the fork tips (5) of the manual pallet jack.
3
4
X
5
4
