13.2.1 Install the external repeater
► Place the external repeater between the wireless connection module and
wireless room thermostat.
► Open the housing with a flat-tip screwdriver.
Fig. 49: Open housing
► Route the line of the plug-in mains unit into the housing from behind.
► Install the repeater.
Fig. 50: Install repeater
► Connect the cable to the external repeater.
Fig. 51: Connect repeater
