User Manual Roth EnergyLogic Touchline/Wireless
Technical data
P100011294 E 117
14.3.4 Performance data
Setting range setpoint +5 to +30 °C
Accuracy (resolution) 0,1 K/0,5 K
Cycle time Ca. 10 min
Dead-time Ca. 50 s
Transmission interval
● 1 … 10 min
● 1 min after change of setpoint or mode of operation
● 10 min for transmission of / 2 … 10 min
Transmitter output
● 12 mW
Activation time (wake-up time) < 2 s
Max. forced refresh time of data wireless
connection module
10 s
Sleeping mode
● Without operation: after max. 5 s
● After programming at user level: 30 s
● After programming at service level: 20 min
14.3.5 Environmental conditions
Ambient temperature 0 to +55 °C
Ambient humidity 5 to 80 % r.F.
Storing and transport temperature –25 to +60 °C
Ingress protection (IP Code) IP 20 (EN 60529)
