User Manual Roth EnergyLogic Touchline/Wireless
Technical data
P100011294 E 115
14.2.4 Outputs
Max. number of thermal actuators
● 4-channel: 6 (2 channels / 2 actuators, 2 channels / 1 actuator)
● 8-channel: 12 (4 channels / 2 actuators, 4 channels / 1 actuator)
● 12-channel: 18 (6 channels / 2 actuators, 6 channels / 1 actuator)
Maximum current per channel
● 250 mA
Outputs for thermal actuators
● 24 V Triac-outputs
● NO (normally open) / NC (normally closed), configurable
● PWM- or On/Off-control
● Shortcut protected
Configurable output for C/O or burner
start
● 230 V / 2.5 A (1) A inductive
● Potential free
● Without time delay and after-run time
Relays for pump output
● 230 V / 2.5 A (1) A inductive
● Potential free
● 2 min delay
● 5 min after-run time
Output 24 V AC
● 24 V / 100 mA
14.2.5 Radio power data
Data transmission
● Room control network: max. 10 min
● System network: max. 3 min
Transmission power < 13 mW
14.2.6 Environmental conditions
Ambient temperature 0 to +55 °C
Ambient humidity 5 to 80 % r.F.
Storing and transport temperature –25 to +60 °C
Ingress protection (IP Code) IP 20 (EN 60529)
